CONCEALED DOOR CLOSER - DC 7003 SIL
Tax included.
Concealed Door Closer
Features
- Closer size EN 3
- Closer fully integrated into door leaf, the guide rail is only visible when the door is open
- Suitable for door shutter thickness of 44mm or more
- Non-handed system
- Hold open unit available
| Product specification | |
| Power size (adjustable by position) | |
| EN3 | Yes |
| Mechanism | Rack and pinion |
| Adjustable closing speed | Yes |
| Adjustable latch action | Yes |
| Maximum door width (mm) | 950 |
| Maximum door weight (kg) | 60 |
| Opening angle | 120° |
| LH and RH doors - universal application | Yes |
| Standard slide rail | Optional |
| Mechanical hold open slide rail | Optional |
| Electromagnetic slide rail | Optional |
