Athmer Drop Down Seal Schall-Ex SlideGS-A - 1-875-0958

Schall-Ex® Slide GS-A

• For sliding doors from 6 mm glass thickness
• Seal and separate cover profile, self-adhesive
• Reduced storage costs
• Suitable for retrofitting

 Technical data

Glass thickness                                                                  ≥ 6 mm

Overall dimensions W x H                                                 15.4 x 45 mm

Actuation                                                                          Single actuation

Sealing profile material                                                      Silicone, self-extinguishing

Travel                                                                                11 mm

Minimum length                                                               235 mm

Standard lengths                                                              708, 833, 958, 1,083, 1,208 mm

Maximum length                                                              1,958 mm

Can be shortened by                                                        125 mm

Individually packed                                                           Foil tube

Article number                                                                 1-875 C-0
